SRS Series

Miniature pneumatic solenoid valve

The SRS miniature solenoid valve is a compact and lightweight 10 mm manifold mount solenoid valve designed for portable instruments and medical devices requiring minimal power consumption and quiet operation. Utilizing an integrated manifold seal design in combination with a variety of electrical termination options, the SRS miniature solenoid valve simplifies pneumatic and electronic integration. With flow rates of up to 18 slpm and inlet pressures of up to 85 psig, the SRS miniature solenoid valve is an ideal solution for demanding portable instruments and medical devices.

Features

  • Lightweight and compact to reduce system size and weight
  • Integrated manifold seal and PC mount capability to simplify integration
  • Hermetically-sealed coil protects the valve from accidental exposure to liquids
  • Constructed of PBT and non-corrosive metal for use with non-reactive gases
  • RoHS compliant
Data sheet

Application areas

  • Medical & analytical gas control
  • Blood pressure monitoring
  • Sensor zeroing
  • Patient monitors
  • Portable medical devices

There's more than meets the eye

This valve option is not quite what you need? We happily customise every product exactly to your needs and to what your project or applications requires.

Alternatively have a look at our other valve options.

there is more than meets the eye like in a tree and its long roots

Similar products:

Variations: SRS-17-1-PV-5-R, SRS-10-1-PV-5-L, SRS-10-2-PV-5-F, SRS-10-2-PV-5-M, SRS-10-2-PV-5-L, SRS-10-1-PV-12-F, SRS-10-1-PV-12-M, SRS-10-1-PV-12-L, SRS-10-2-PV-12F, SRS-10-2-PV-12-M, SRS-10-2-PV-12-L, SRS-10-1-PV-24-F, SRS-10-1-PV-24M, SRS-10-1-PV-24L, SRS-10-3-PV-24-L, SRS-11-1-PV-5-F, SRS-11-1-PV-5-L, SRS-11-2-PV-5-L, SRS-11-1-PV-12-F, SRS-11-1-PV-12-M, SRS-11-1-PV-12-L, SRS-11-2-PV-12-F, SRS-11-2-PV-12-M, SRS-11-2-PV-12-L, SRS-11-3-PV-12M, SRS-11-3-PV-12L, SRS-11-1-PV-24-M, SRS-11-1-PV-24-L, SRS-11-2-PV-24-F, SRS-11-2-PV-24-M, SRS-11-2-PV-24-L, SRS-11-3-PV-24-L, SRS-13-1-PV-5-F, SRS-13-1-PV-5-M, SRS-13-1-PV-5-L W/SCREWS, SRS-13-2-PV-5-F, SRS-13-2-PV-5-M, SRS-13-2-PV-5-L, SRS-13-1-PV-12F, SRS-13-1-PV-12-M, SRS-13-1-PV-12-L, SRS-13-2-PV-12F, SRS-13-2-PV-12-M, SRS-13-2-PV-12-L, SRS-13-1-PV-24-F, SRS-13-1-PV-24-L, SRS-13-2-PV-24-F, SRS-13-2-PV-24-M, SRS-13-3-PV-24-L, SRS-13-1-PV-5-R, SRS-14-1-PV-5-F, SRS-14-1-PV-5-L, SRS-14-2-PV-5-L, SRS-14-3-PV-5-L, SRS-14-1-PV-12F, SRS-14-1-PV-12M, SRS-14-1-PV-12-L, SRS-14-2-PV-12-F, SRS-14-2-PV-12-L, SRS-14-3-PV-12L, SRS-14-1-PV-24-F, SRS-14-1-PV-24-M, SRS-14-1-PV-24-L, SRS-14-2-PV-24-F, SRS-14-2-PV-24-M, SRS-14-2-PV-24L, SRS-14-3-PV-24-L, SRS-14-1-PV-5-R, SRS-16-1-PV-5-F, SRS-16-1-PV-5-L, SRS-16-2-PV-5-F, SRS-16-2-PV-5-M, SRS-16-2-PV-5-L, SRS-16-3-PV-5-F, SRS-16-1-PV-12-F, SRS-16-1-PV-12-M, SRS-16-1-PV-12-L, SRS-16-2-PV-12F, SRS-16-2-PV-12-M, SRS-16-2-PV-12-L, SRS-16-3-PV-12-F, SRS-16-3-PV-12-M, SRS-16-3-PV-12-L, SRS-16-1-PV-24-F, SRS-16-1-PV-24-M, SRS-16-1-PV-24-L, SRS-16-2-PV-24-M, SRS-16-2-PV-24-L, SRS-16-3-PV-24-F, SRS-16-3-PV-24-L, SRS-16-1-PV-5-R, SRS-16-1-PV-12-R, SRS-16-1-PV-24-R, SRS-17-1-PV-5-M, SRS-17-1-PV-5-L, SRS-17-2-PV-5-F, SRS-17-2-PV-5-L, SRS-17-3-PV-5-L, SRS-17-1-PV-12F, SRS-17-1-PV-12-M, SRS-17-1-PV-12-L, SRS-17-2-PV-12-F, SRS-17-2-PV-12-M, SRS-17-2-PV-12-L, SRS-17-3-PV-12-F, SRS-17-3-PV-12-M, SRS-17-3-PV-12-L, SRS-17-1-PV-24-F, SRS-17-1-PV-24-M, SRS-17-1-PV-24-L, SRS-17-2-PV-24-F, SRS-17-2-PV-24-M, SRS-17-2-PV-24-L, SRS-17-3-PV-24M, SRS-17-3-PV-24L, SRS-17-1-PV-24R, SRS-17-2-PV-24-R, SRS-11-3-PV-24-R
